Fricker Top Hat Aluminium Grid is a ceiling grid that is the system of choice for premium commercial office developments. Proudly Australia made and owned.
Fricker Top Hat Aluminium Grid System
Product Properties
- 33mm Face
- Mitred for a clean, streamlined look. Available in 1200×1200, 1350 x 1350 & 1500 x 1500 modules. Contact CSR Himmel for customised modules.
- Extruded aluminium finish
- Colour Fricker White
| Product | Size | Each/Carton |
|---|---|---|
| Main Runner – Mitred | 3600x50x33mm 4050x50x33mm 4500x50x33mm |
24 |
| Cross Runner – Mitred | 1200x50x33mm 1350x50x33mm 1500x50x33mm |
24 |
| Shadowline Wall Angle | 3660x10x10mm | 30 |
| Wall Angle 20mm | 3250x25x20mm | 10 |
| Product | Each/Carton |
|---|---|
| Main Runner Joiner Clip | 100 |
| Suspension Clip | 100 |
| Dead End Light Clip | 100 |
Fricker Aluminium Ceiling Grid is a premium system that is designed for high end commercial applications. Manufactured in Sydney, the Fricker Aluminium Ceiling Grid range is available in Top Hat, Flush Face and Slimline profiles and can be manufactured in 1200 x 1200mm, 1350 x 1350mm and 1500 x 1500mm module (modules can include 2 – 5 tiles). CSR Himmel can deliver an Aluminium Grid System that is customisable to your project needs.
Fricker is available in a diverse range of solutions to suit various commercial developments including offices, education facilities, healthcare facilities, retail and industrial developments.
Fricker is proudly Australian Made and Owned.
Installation
Detailed assembly procedures, including drawings, are available on request and should be viewed in conjunction with these instructions. Technical assistance is also available on request.
Maintenance
Marks can be removed using a soft damp cloth with a mild liquid detergent. Stubborn marks may be removed using a soft cream cleanser on a soft damp cloth, however, excessive rubbing should be avoided as scratching or permanent marking of the powder coat surface may result.
